Setting up an AppScan Presence to scan a GitHub repository directly.
You can use an AppScan Presence to run static analysis on GitHub Enterprise repositories.
AppScan Presence includes optional support for running static analysis on GitHub repositories from a GitHub Enterprise server using a GitHub App. The GitHub server doesn’t have to be publicly accessible; however, the AppScan user must have network access to the GitHub server and permission to access the repositories in GitHub.
An instance of an AppScan Presence with GitHub scanning enabled can be associated with one GitHub Enterprise server using one GitHub App defined on the server.
- Create and install an AppScan Presence to a folder location
on a private network with access to the GitHub Enterprise server.Note: A single Presence connected to a single GitHub server allows all the users in the organization to scan repositories on that server to which they have access..
- Create a GitHub App on the GitHub Enterprise server.
- Activate and configure GitHub-specific parameters in the AppScan Presence.
- Create the scan.
Create a GitHub App
Review information about GitHub Apps before you begin.
To create a GitHub App to work with the AppScan Presence:
- Log in to GitHub.
- Select New GitHub App. , the cliek
- Specify the following app parameters:
Parameter Value GitHub App name Your name for the app. Decription A description of the app. For example, "ASoC connector to development server." Homepage URL The HCL AppScan on Cloud URL. For example, https://cloud.appscan.com
.Callback URL Your AppScan Presence URL plus /signin-github
. For example,https://www.example.com/signin-github
.Webhook Uncheck Active Repository permissions Contents and Metadata set to Read-only. Account permissions Email addresses set to Read-only. Where can this GitHub App be installed? Any account. - Click Create GitHub App.
- View the GitHub App settings and take note of the following values for
configuring the AppScan Presence.
AppID
AppUrl
ClientId
ClientSecret
Configure and activate an AppScan Presence
- Create a private key for the GitHub App:
- In GitHub Enterprise, under the GitHub App window, click Generate a private key.
- Rename the downloaded file
GitHubAppKey.pem
and copy it to the Presence installation folder.
- In the Presence installation directory, locate the
git_connect_settings.json
file and open it for editing. - In the
GitConnectOptions
section ofgit_connect_settings.json
, edit parameters as follows:Parameter Description Example GitServerName
The name of the GitHub server. github01
GitConnectUrl
The URL of the web application exposed by this presence. https://my-host-fqsn:44
GithubAppId
AppId of the GitHub App you created for this connection. 55
GithubAppUrl
Installation URL of the GitHub App. https://github01.example.com/github-apps/asoc
ClientId
Client ID of the of the GitHub App. <oauth client id>
ClientSecret
Client secret of the GitHub App. <oauth client secret>
GitPlatformDomain
URL for the GitHub Enterprise server. https://github01.example.com Proxy
If a proxy is required to connect to the GitHub server, uncomment this line and provide the proxy details. 127.0.0.1:8888
Active
Enable or disable GitHub connection functionality in the AppScan Presence. The default value is false
.true
- We highly recommend using HTTPS; if you choose to use HTTP, the site is
considered insecure and as such you must adjust browser settings to allow
insecure content.
To ensure you are using HTTPS, in the
Kestrel
section ofgit_connect_settings.json
, edit paramters as follows:Parameter Description Example Http
The protocol to be used by the AppScan Presence. Https
Url
The port to be used by the AppScan Presence. http://*:8080 Note: AppScan Presence uses Kestrel to host its web application. Kestrel is an embedded web server and it can be configured using the Kestrel section in the configuration file. For more information on the structure of this server configuration, see Configure endpoints for the ASP.NET Core Kestrel web server. - Install the GitHub App on the account that owns it:
- Open the public link for the app (
GithubAppUrl
) in a browser. - Insall the app.
Note: It is not necessary to grant access for this installation to the private repositories, but the application should be installed on the account that owns it. - Open the public link for the app (
Once the configuration is set, the Presence can be started (or restarted) and scanning can begin. Logs are written to the console and to log files located under the logs folder.
AppScan Presence GitHub scanning flow
The following illustrates the flow of scanning a repository from a GitHub Enterprise server using an AppScan Presence:
- The user logs in to ASoC. (1,2)
- From ASoC, a list of configured enabled Presences with the connected servers is returned. The user then chooses the GitHub server to use for the scan. ASoC returns the URL for accessing the AppScan Presence server and the URL to the GitHub server
- When the user clicks Connect to GitHub, ASoC opens a new browser tab that points to AppScan Presence (3) which initiates the
oAuth
Authorization code flow. The user is then redirected to the GitHub Ent Server (4), logs in, consents to AppScan Presence accessing the GitHub account, and then is redirected back the AppScan Presence with the authorization code - AppScan Presence gets the user access token
from the GitHub Ent server (5) and sends it back to the user (3) together
with a script that sends the token to ASoC using
window.postMessage
. - ASoC uses the GitHub access token (4) to get a list of repositories that are accessible by the user and to the GitHub App that is used by AppScan Presence. The user can then choose a repository to scan.
- Before a scan is created for the selected repository, ASoC verifies that the repository is accessible by the user. The AppScan Presence API (3) function RepoSignature creates a signature for the repo details (repo owner and repo name). Once access is verified, the repo details are signed with a private key that is unique for the AppScan Presence. The signature is returned by the API call to ASoC.
- ASoC creates a scan using UsersAPI (2) by provisioning the Presence ID (Git Connect), the repository details and the signature. UserAPI verifies the signature using a public key associated with the provided AppScan Presence instance. If the validation succeeds, a scan is created for the repository.
- The Presence service, which polls the Presence WebAPI (6) for tasks, gets a new task to fetch the scanned repository. The Presence connects to the GitHub Ent server (7) using the associated GitHub App private key, fetches the repository as zip file, and streams it to the Presence WebAPI (UploadRepo)
- The repository zip file is stored in ASoC and can be scanned. When the scan is done, the results are viewed and analyzed in ASoC. The results contain links to the GitHub Ent server, referencing the relevant lines in the code for triage and remdiation. ASoC can open a new tab with the relevant code.
