Deploying HCL CDP SMSEmailSender

This section provides detailed instructions on how to deploy HCL CDP SMS Email Sender using the Devtron in the OpenShift.

Before you begin

Make sure to create a cdp-smsemailsender secret in the HashiCorp vault before deploying the HCL CDP SMSEmailSender.

To create a CDP SMS Email Sender secret in the HashiCorp vault, follow the steps below:

Create a cdp-smsemailsender secret sample key and value, and update the actual values as shown below.

{
"KafkaBootstrapServer": "bootstrap.servers::<KAFKA_HOST_1>:9096,<KAFKA_HOST_2>:9096",
"KafkaUsername": "<KAFKA_USER>",
"KafkaPassword": "<KAFKA_PASSWORD>",
"VrmDbUsername": "<DB_USER>",
"VrmDbPassword": "<DB_PASSWORD>",
"KafkaProducerHostName": "trigger-sender-mu",
"ADCB_DEVMAG_CERTIFICATE_PASSWORD": "",
"ADCB_PRODMAG_CERTIFICATE_PASSWORD": "",
"s3.accessKeyId": "",
"s3.secretKey": "",
"s3.region": "ap-south-1",
"RedisIP": "<REDIS_HOST>",
"RedisPort": "6379",
"MysqlHost": "<DB_HOST>",
"MysqlPort": "3307",
"MysqlDb": "vrm?autoReconnect=true",
"5979_ACL_USER_ID": "",
"5979_ACL_PASS": "",
"5979_ACL_APP_ID": "",
"5979_ACL_SUB_APP_ID": "",
"BLOW_FISH_KEY": "<SECRET_KEY>",
"MGAGE_XML_API": "<API_KEY>",
"KENSCIO_CLIENT_END_POINT_URL": "",
"KENSCIO_USERNAME": "",
"KENSCIO_PASSWORD": "",
"KENSCIO_SYSTEM_ID_KEY": "",
"KENSCIO_SYSTEM_ID": "",
"KENSCIO_MESSAGE_ID_KEY": "",
"KENSCIO_MESSAGE_ID": "",
"AerospikeCluster": "<AERO_HOST_1>,<AERO_HOST_2>",
"AerospikePort": "13000",
"Namespace": "cdpstore",
"Expiry": "-1",
"Timeout": "3000",
"USAerospikeCluster": "",
"USAerospikePort": "13000",
"USNamespace": "",
"MUAerospikeCluster": "<AERO_HOST_1>,<AERO_HOST_2>",
"MUAerospikePort": "13000",
"MUNamespace": "cdpstore",
"SupportedRegion": "aps1",
"ExcludedCampaigns": "",
"KAFKA_TOPIC_LIST": "dmp_sms_core_aps1,dmp_email_core_aps1,dmp_wsap_core_aps1,dmp_trapi_core_aps1",
"KAFKA_TOPIC_CONSUMERS": "6,6,6,6",
"KAFKA_TOPIC_CONSUMER_BATCHSIZE": "10,10,10,10",
"KAFKA_TOPIC_CONSUMER_DEFAULT_BATCH_TIMEOUT_MS": "1000,1000,1000,1000",
"KAFKA_TOPIC_CONSUMER_DEFAULT_BATCHTIMEOUT_TRIGGER": "5000,5000,5000,5000",
"TSDB_HOST": "<TSDB_HOST>",
"allowTrafficForSpecificCampaign": "false",
"IncludedCampaigns": "4658,6035,6238,6037,6184,6349,6450,6455,6525",
"URL_SHORTENER_S3_BUCKET": "lem-url-shortener",
"URL_SHORTENER_S3_BUCKET_EMAIL": "lem-email-url-shortener",
"PII_MIN_IDLE_THREADS": "2",
"PII_MAX_IDLE_THREADS": "4",
"KafkaBootstrapServerUS": "",
"KafkaUsernameUS": "",
"KafkaPasswordUS": "",
"SesEnabled": "true",
"PIILookUpEnabled": "true",
"KafkaConsumerConfig": "bootstrap.servers::<KAFKA_HOST_1>:9096,<KAFKA_HOST_2>:9096|security.protocol::SASL_SSL|sasl.jaas.config::org.apache.kafka.common.security.scram.ScramLoginModule required username='<KAFKA_USER>' password='<KAFKA_PASSWORD>';|sasl.mechanism::SCRAM-SHA-512|client.dns.lookup::use_all_dns_ips|group.id::k8s-trigger-sender",
"KafkaProducerConfig": "bootstrap.servers::<KAFKA_HOST_1>:9096,<KAFKA_HOST_2>:9096|security.protocol::SASL_SSL|sasl.jaas.config::org.apache.kafka.common.security.scram.ScramLoginModule required username='<KAFKA_USER>' password='<KAFKA_PASSWORD>';|sasl.mechanism::SCRAM-SHA-512|client.dns.lookup::use_all_dns_ips|acks::all|max.block.ms::5000",
"KafkaProducerRegion": "aps1",
"KafkaProducerConfigaps1": "bootstrap.servers::<KAFKA_HOST_1>:9096,<KAFKA_HOST_2>:9096|security.protocol::SASL_SSL|sasl.jaas.config::org.apache.kafka.common.security.scram.ScramLoginModule required username='<KAFKA_USER>' password='<KAFKA_PASSWORD>';|sasl.mechanism::SCRAM-SHA-512|client.dns.lookup::use_all_dns_ips|acks::all|max.block.ms::5000",
"AerospikeUser": "<AERO_USER>",
"AerospikePassword": "<AERO_PASSWORD>"
}

Update ConfigMaps data with actual values, and create required Kafka topics before deployment.

Procedure

Navigate to the Devtron Chart Store, and select the cdp-smsemailsender chart to deploy.
Now, configure and deploy the cdp-smsemailsender charts.

In the YAML section, update the ConfigMap using the below details and deploy the chart.

KAFKA_EXECUTOR_SERVICE_MIN_THREADS: "32"
KAFKA_EXECUTOR_SERVICE_MAX_THREADS: "64"
KAFKA_EXECUTOR_SERVICE_THREAD_TTL: "5"
KAFKA_EXECUTOR_SERVICE_QUEUES_SIZE: "1000"

TRAPI_KAFKA_EXECUTOR_SERVICE_MIN_THREADS: "32"
TRAPI_KAFKA_EXECUTOR_SERVICE_MAX_THREADS: "64"
TRAPI_KAFKA_EXECUTOR_SERVICE_THREAD_TTL: "5"
TRAPI_KAFKA_EXECUTOR_SERVICE_QUEUES_SIZE: "1000"

MAX_EVENT_BATCH_LAG: "16"
KAFKA_CONSUMER_GROUP: k8s-trigger-sender

EMAIL_HTTPS_CONNECTION_COUNT: "10"
EMAIL_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "6000"

MANDRILL_CLIENT_END_POINT_URL: "<masked-email-provider>"

kMS_DECRYPT_TIMEOUT: "3"

FROM_EMAIL_ID: user@domain.com
ALERT_TO_EMAIL_ID: user@domain.com

SMS_HTTPS_CONNECTION_COUNT: "10"
SMS_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "6000"

REDIS_MAX_CONNECTIONS: "20"
REDIS_KEY_TTL_IN_SEC: "7776000"

TRAPI_HTTPS_CONNECTION_COUNT: "45"
TRAPI_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "4000"
TRAPI_HTTPS_CONNECTION_READ_TIMEOUT_SECONDS: "122"
TRAPI_HTTPS_CONNECTION_WRITE_TIMEOUT_SECONDS: "123"
TRAPI_HTTPS_CONNECT_TIMEOUT_SECONDS: "124"

CLICK_TRACKER: "<masked-tracker-url>"
CLICK_TRACKER_SMS: "<masked-tracker-url>"
OPEN_TRACKER: "<masked-tracker-url>"

PASS_THROUGH_SUPPORTED_VENDOR: Phonon

DB_REFRESH_INTERVAL_MS: "120000"
TRAPI_CONFIG_REFRESH_INTERVAL: "600000"

MINIMUM_IDLE_THREADS: "3"
MAXIMUM_IDLE_THREADS: "6"

TRAPI_TOPIC_PREFIX: dmp_trapi_core

S3_ENDPOINT: "<masked-s3-endpoint>"
S3_PROTOCOL: HTTPS
S3_MAX_ERROR_RETRY: "3"
S3_MAX_CONNECTIONS: "10"
S3_MAX_RW_RETRY: "3"
S3_TIMEOUT_SOCKET: "5000"
S3_TIMEOUT_CONNECTION: "10000"
S3_TIMEOUT_CLIENTEXECUTION: "50000"
S3_TIMEOUT_REQUEST: "5000"
S3_REQUEST_METADATA_FOLDER: trapi_req_metadata

URL_SHORTENER_DOMAIN: "<masked-shortener-domain>"
URL_SHORTENER_DOMAIN_EMAIL: "<masked-shortener-email-domain>"
URL_SHORTENER_AVOID_CONFLICT: "true"
URL_SHORTENER_CONFLICT_MAX_RETRIES: "3"
URL_SHORTENER_MULTIPLY_FACTOR: "10000"

SHORTEN_CLICK_TRACKER_EMAIL: "<masked-shortener-url>"

KAFKA_PRODUCER_POOL_SIZE: "10"
KAFKA_PRODUCER_META: "true"
PRODUCER_EVENT_TYPE: "1234"

CELERY_PARAM_SENDER: SENDER_aps1
CELERY_PARAM_IGNORE: IGNORE_IF_PRESENT
CELERY_TOPIC: CeleryETA

KAFKA_PRODUCER_CHANNELS: email,sms,trapi,wasp

EMAIL_IMPRESSION_TOPIC: sms_email_events
SMS_IMPRESSION_TOPIC: sms_email_events
TRAPI_IMPRESSION_TOPIC: trapi_events
TRAPI_FEEDBACK_IMPRESSION_TOPIC: sms_email_events
WASP_IMPRESSION_TOPIC: whatsapp_events

USER_FAILURE_KAFKA_TOPIC: sender_failure

ADCB_DEVMAG_TRAPI_CERTIFICATE_FILE_PATH: "<masked-cert-path>"
ADCB_DEVMAG_TRAPI_CERTIFICATE_S3_FILE_PATH: "<masked-cert-path>"
ADCB_PRODMAG_TRAPI_CERTIFICATE_S3_FILE_PATH: "<masked-cert-path>"
ADCB_PRODMAG_TRAPI_CERTIFICATE_FILE_PATH: "<masked-cert-path>"
TRAPI_CERTIFICATE_ENDPOINT: "<masked-cert-service>"
TRAPI_CERTIFICATE_CAMPAIGN_SUFFIX: "<masked-value>"

COMPONENT_NAME: trigger_sender_us

REPORTING_INTERVAL_IN_MIN: "55"

WHATSAPP_HTTPS_CONNECTION_COUNT: "120"
WHATSAPP_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "10"

METRIC_FILE_PATH: /disk1/config/sms-email-sender/metrics.ini
METRIC_DUMPER_FILE_PATH: /disk1/config/sms-email-sender/metricDumper.ini

HTTPS_CONNECTION_COUNT: "10"
HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "60"

SERVER_PORT: "8085"

COMMON_HTTPS_CONNECTION_COUNT: "100"
COMMON_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "60"

ADCB_STAGE_HTTPS_CONNECTION_COUNT: "10"
ADCB_STAGE_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "600"
ADCB_STAGE_HTTPS_CONNECTION_READ_TIMEOUT_SECONDS: "125"
ADCB_STAGE_HTTPS_CONNECTION_WRITE_TIMEOUT_SECONDS: "120"
ADCB_STAGE_HTTPS_CONNECT_TIMEOUT_SECONDS: "130"

ADOBE_HTTPS_CONNECTION_COUNT: "15"
ADOBE_HTTPS_CONNECTION_KEEP_ALIVE_SECONDS: "120"
ADOBE_HTTPS_CONNECTION_READ_TIMEOUT_SECONDS: "900"
ADOBE_HTTPS_CONNECTION_WRITE_TIMEOUT_SECONDS: "900"
ADOBE_HTTPS_CONNECT_TIMEOUT_SECONDS: "124"

SENDER_FEEDBACK_TOPIC: dmp_sst_nba_di_api

LIVSPACE_IVR_LPEU_APID: "99"
LIVSPACE_IVR_BPEU_APID: "89"

APP_TYPE: trigger-sender-us
APP_REGION: ap-south-1
APP_INFRA: k8s

LOG_LEVEL_APP: debug
LOG_LEVEL_METRICS: info
LOG_LEVEL_UTILS: debug
LOG_LEVEL_PII_STORAGE: debug
LOG_LEVEL_KMS: debug
LOG_LEVEL_ROOT: info

S3_ACCESSKEYID: ""
S3_SECRETKEY: ""
S3_REGION: ap-south-1

defaultBusinessRegion: aps1
inboundKafkaTopic: sender_inbound

ergoLeadApi: "<masked-api>"

VRM_DRIVER: org.mariadb.jdbc.Driver
DBDRIVER: jdbc:mariadb

TSDB_PORT: "80"

KafkaProducerConfiguse1: "<masked>"
KafkaProducerConfigtaw1: "<masked>"

KENSCIO_USERNAME: "<masked>"
KENSCIO_PASSWORD: "<masked>"
KENSCIO_SYSTEM_ID_KEY: "<masked>"
KENSCIO_SYSTEM_ID: "<masked>"
KENSCIO_MESSAGE_ID_KEY: "<masked>"
KENSCIO_MESSAGE_ID: "<masked>"

ADCB_DEVMAG_CERTIFICATE_PASSWORD: "<masked>"
5979_ACL_USER_ID: "<masked>"
5979_ACL_PASS: "<masked>"
5979_ACL_APP_ID: "<masked>"
5979_ACL_SUB_APP_ID: "<masked>"

BLOW_FISH_KEY: "<masked>"

MGAGE_XML_API: "<masked>"

emailType: SES
KMS_IMPLEMENTATION: AWS

On successful deployment, validate the deployment as shown below.
